SP950 Syringe Pump

SP950 Syringe Pump Specification

Type
Syringe Pump

Material
ABS Engineering Plastic & Stainless Steel

Properties
High Precision Motor, Microcomputer Controlled

Color
White & Blue

Application
Infusion of Drugs & Fluids

Disposable
No

Recyclable
Yes

Sterilized
No

Needle
Not Included

Use Type
Reusable

Regulator Specification
Micro-step Flow Regulation

Connector Specification
Standard Syringe Holders

Air Vent Type
Automatic Air Bubble Detection

Sterilization Mode
Not Required (Device is Non-Contact with Fluids)

Shelf Life
5 Years

Weight
Approx. 2.5 kg

Storage Temperature
-10C to 55C

Power Supply
AC 220V 10%, 50Hz/60Hz; Rechargeable Internal Battery

Accuracy
2%

Operation Method
User-Friendly Keypad

Operating Temperature
5C to 40C

Safety Features
Lockable Panel, KVO Function, Anti-Bolus protection

Display
Large LCD Display

Syringe Compatibility
5ml, 10ml, 20ml, 30ml, 50ml standard syringes

Flow Rate Range
0.1 ml/h to 1500 ml/h (depending on syringe size)

Mounting
Pole Clamp Included

Infusion Modes
Flow Rate Mode, Time Volume Mode, Body Weight Mode, Dose Rate Mode

Relative Humidity
10%-90% (No condensation)

Battery Backup
Up to 6 Hours

Alarms
Occlusion, End-Line, Low Battery, Error, Syringe Not Installed

SP950 Syringe Pump Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About SP950 Syringe Pump

It is a medical Syringe Pump, features in high intelligence, high safety, simple operation and stable working; displaying real-time parameters accurately by an LCD audible, visible and text alarm; high injection accuracy; detecting the syringe specification automatically. It waswidely used in medical institutions for clinical nursing and various occasions for intravenous injection, such as ICU, CCU, neonatology, obstetrics and gynecology, pediatrics, internal medicine, surgery, operating room, emergency room, etc.

Function

Injection rate and total volume can be set by users.
High priority alarms: occlusion, syringe out, motor abnormity, no syringe installed, battery exhaustion, enter KVO, pressure failure,etc. General alarms: near completion, low battery and standby prompt.
With bolus injection function,convenient for supplying temporary and rapid medication.
Enter KVO mode after the injection is completed.
With a built-in rechargeable battery, it can automatically switch to battery-powered when power is interrupted and automatically charge once power-on.
2.8" LCD.
Audible, visible and text prompt function.
The system parameter and syringe type settings are protected by the password, prevents changes.
The disposable syringe met national standards can be used, and the accuracy can be ensured by adjusting parameters.

Physical characteristic

Dimension: 305 mm (L) x 132 mm (W) x 114 mm (H)
Weight: 1.7 Kg

Accessories

A versatile bracket
A power cord
A user manual

Performance

Specification for syringe:10 ml/20 ml/30 ml/50 ml syringe met national standards

Injectionrate:

10ml 0.1 ml/h-200ml/h
20 ml 0.1 ml/h-400 ml/h
30ml 0.1 ml/h-600ml/h
50 ml 0.1 ml/h-1200 ml/h

Bolus rate:

10 ml 200 ml/h
20 ml 400 ml/h
30 ml 600 ml/h
50ml 1200ml/h

Accumulated volume: 0 ml-9999 ml

Injection accuracy: -/+ 3%

Pressure range of occlusion alarm:

Low: 40kPa (-/+16kPa)
Middle: 70 kPa (-/+30 kP)
High: 100 kPa (-/+35 kPa)
KVO rate:0.1 ml/h
Class: Class II, type BF applied part,intermally powered equipment
Alarm: occlusion, syringe out, motor abnormity, pressure failure, enter KVO, battery exhaustion, no syringe installed, near completion, low battery and standby prompt.
Maximal power consumption: 25 VA, at least4-hour continuous operation at the injection rate of 5 ml/h after fully charged.
Power supply: AC:100-240V, 50/60Hz
Battery: lithium battery, 7.4V, 5000 mAh

Versatile Infusion Options

Accommodating standard syringes from 5ml to 50ml, the SP950 Syringe Pump offers adaptable usage based on clinical needs. Users can select from Flow Rate, Time Volume, Body Weight, or Dose Rate modes, ensuring optimal drug delivery tailored for each patient. With micro-step flow regulation and a wide flow rate range, precision is consistently maintained.

Advanced Safety and User-Friendly Features

Designed for safety, the SP950 comes with multiple alarm types, lockable panels, and functions like Anti-Bolus and KVO, safeguarding patient care during infusions. The intuitive keypad and large LCD display make setup and monitoring straightforward for medical staff, while automatic air bubble detection enhances reliability.

Robust Build and Reliable Operation

Constructed from ABS engineering plastic and stainless steel, this pump is durable and easy to maintain. It is reusable, non-disposable, and recyclable. With a rechargeable internal battery providing up to 6 hours of backup, it remains dependable even during power interruptions. Its pole clamp ensures convenient mounting in diverse healthcare settings.

FAQ's of SP950 Syringe Pump:

Q: How does the SP950 Syringe Pump ensure accurate fluid and drug delivery?

A: The SP950 utilizes a high precision motor and microcomputer control to maintain a delivery accuracy of 2%. Its micro-step flow regulation system provides consistent and precise infusion, with multiple safety checks including alarms for occlusion, end-line, and syringe installation errors.

Q: What types of syringes are compatible with the SP950 Syringe Pump?

A: This pump supports standard disposable syringes ranging from 5ml, 10ml, 20ml, 30ml, to 50ml, allowing for flexibility in different clinical scenarios.

Q: When should I use the different infusion modes on the SP950?

A: Choose Flow Rate Mode for direct control over infusion speed, Time Volume Mode to infuse a set volume over a specific period, Body Weight Mode for weight-based dosing, and Dose Rate Mode for infusing drugs prescribed per dose per hour-ideal for tailored treatments.

Q: Where can the SP950 Syringe Pump be mounted during operation?

A: It comes with a secure pole clamp, making it easy to attach the pump to IV stands or hospital bed rails for stability and accessibility in varied clinical environments.

Q: What are the safety features included with the SP950 Syringe Pump?

A: Key safety features include occlusion and end-line alarms, lockable panel to prevent unauthorized changes, KVO (keep vein open) function, Anti-Bolus protection, automatic air bubble detection, and reliable alarm notifications to enhance patient safety.

Q: How is the device powered and what is the battery backup duration?

A: The SP950 operates on AC 220V (50Hz/60Hz) and features a rechargeable internal battery providing up to 6 hours of backup, ensuring continuous operation even during power outages.

Q: What maintenance or sterilization processes are required for the SP950?

A: Since the SP950 does not come into direct contact with fluids and syringes are disposable, no sterilization is needed for the device itself. Routine exterior cleaning and regular checks for functional alarms and updates are recommended for optimal use.
